Bellow Seal Gate Valve
- Home
- Products
- Industrial Valve
- Angle Seat Valve
- Pneumatic angle seat valve
- 100 Series Pneumatic Angle Seat Valve
Technical Parameters
Product: ASTM A216 WCB Bellow Seal Gate Valve.
Size: 2-12 Inch.
Wall thickness: API 600.
General valve design: API 600 & MSS SP-117.
End to End dimensions: ASME B16.10.
Flange design: ASME B16.5.
Butt Weld design: ASME B16.25.
Body & Bonnet: ASTM A216 WCB.
Wedge: ASTM A216 WCB+316 Faced.
Seat Ring: Carbon Steel + Stellite 6 Faced.
Stem: SST 316.
Gland: SST 316.
Packing: Graphite, PTFE.
Hand Wheel: Malleable lron or Steel.
Other Features
Bolted Bonnet
Cast Carbon, Stainless Steel or Alloy Steel
Flanged ends or butt weld ends
Hydro-formed bellows
