Bolted Bonnet Gate Valve
- Home
- Products
- Industrial Valve
- Angle Seat Valve
- Pneumatic angle seat valve
- 100 Series Pneumatic Angle Seat Valve
Technical Parameters
Body/Bonnet: ASTM A216 WCB
Wedge: ASTM A216 WCB+13CR
Seat: ASTM A105+13CR
Stem: 13CR
Size: 30 Inch, DN750
Pressure: Class 600 LB, PN100
Face to face dimension: 1651 mm
Standard: API 600
RF standard: ASME/ANSI B16.47
Sealing pressure test: 112 BAR
Shell pressure test: 153 BAR
